Product introduction:
Raymond Micronizer Mill,Micronizer,Micronizer Mill,Micronizer Machine,Stone Micronizer,Limestone Micronizer: Shanghai Clirik Machinery Co., Ltd is a large professional manufacturer of Raymond Micronizer Mill.The Clirik Raymond micronizer mill have five models: YGM7815,YGM8314,YGM9517,Y
Raymond micronizer mill, micronizer machine:
Shanghai Clirik Machinery Co., Ltd is a large professional manufacturer of Raymond micronizer mill,The Clirik Raymond micronizer mill have five models: YGM7815,YGM8314,YGM9517,YGM4121,MTM1600.
Shell Size:15-35mm
Grinding Weight:1.2 – 11 T
Application:The Raymond micronizer mill is widely used in small and medium mining, chemicals, building materials, metallurgy, refractories, pharmaceuticals, cement and other industries.
Raw Material:such as gypsum, talc, calcite, limestone, marble, barite, dolomite, granite, kaolin, bauxite, fly ash , oxidation iron oxide red, iron ore, etc.
Output:30 – 425 mesh
Introduction of Raymond micronizer mill:
Raymond micronizer mill, also known as Raymond Grinder or Pendulum Grinder, is designed by Clirik Machinery with Germany technology. The Raymond micronizer mill is more efficient than ball mill in some area, with features of closed circuit for high fine powder devices.
Raymond micronizer mill Features :
1.Low production cost, high-performance
Overall for the vertical structure, small footprint, systematic, from raw material delivered to the milling and roughing to final packaging, of an independent production system
2.Good stability, high reliability
Raymond Host transmission device adopts enclosed gear boxes and pulleys, transmission smooth, reliable operation.
3.Perfect particle size
Electrical system adopts centralized control, milling workshop basic enabling unmanned operation.
Structure of Raymond micronizer mill
Raymond micronizer mill is mainly composed of main unit, analyzer, fan, dischargeing cyclone separator, powder cyclone separator and air duct. Among them, the main unit consists of frame, blow shell, shovel, grinding roller and grinding ring.
Working principle of Raymond micronizer mill
The rollers tightly rolled on the ring under the effect of centrifugal force. Shovel sends material between the roller and ring and the material is grinded into powder under the high pressure.Then the fan blows the power up into the analyzer. At this time, the power material met the fineness requirement get through the analyzer and get into the power cyclone separator while the others will be sent back for re-grinding.The whole system is airtight circulation.
Technical Parameter of Raymond micronizer mill:
| Type | Roller | Max. feeding size(mm) | Fineness of product(mm) | Output (t/h) | Power of machine(KW) | Size(mm) | ||
| No. | Dimension(mm) | Height(mm) | ||||||
| YGM7815 | 3 | 260 | 150 | 15 | 0.613-0.033 | 1-3 | 18.5 | 4300*3500*5100 |
| YGM8314 | 3 | 270 | 140 | 20 | 0.613-0.033 | 1.2-4.6 | 22 | 5300*4100*5200 |
| YGM9517 | 4 | 310 | 170 | 25 | 0.613-0.033 | 2.1-5.6 | 37 | 7100*5900*7900 |
| YGM4121 | 5 | 410 | 210 | 30 | 0.613-0.033 | 2.8-10.5 | 75 | 9200*7250*9700 |
| MTM1600 | 6 | 440 | 270 | 35 | 0.613-0.033 | 5-20 | 132 | 12550*5700*8350 |
Notice: Any change of Raymond micronizer mill technical data shall not be advised additionally.
Raymond micronizer mill Price
If you want to know the Raymond micronizer mill price or have any questions about Raymond micronizer mill, please do not hesitate to contact us.
