Micronizer mill is made to produce fine and superfine powder of non-inflammable, non-explosive and brittle materials with Mohs's hardness under six, such as calcite, chalk, limestone, dolomite, kaolin, bentonite, talc, mica, magnesite, illite, pyrophyllite and vermiculite, sepiolite, attapulgite, rectorite, diatomite, barite, gypsum, alunite, graphite, fluorite, rock phosphate, Kalium ore, pumice, etc., totally more than 100 kinds of materials.
Bentonite micronizer mill is professionally producing bentonite fine and superfine powder. Micronizer mainly consisit of main unit, classifier, powder collector, dust cleaner, induced draft fan, muffler, sound-proof room, crushe, bucket elecator, storage hopper, and vibrating feeder.
Compared with other companies grinding equipment, Shanghai Clirik Machinery Co. Ltd. grinding equipment has the following Features and advantages :
1) High efficiency
2) Long lifecycle of grinding mill spare partsf
3) High safety and reliability
4) High fineness and flexible adjustment
6) Advanced intelligent speed control device
Working Principle of Micronizer mill
After crushed by hammer crusher, the large materials become small ones and are sent to storage hopper by elevator, and then evenly sent to the upper distribution plate of the turnplate by vibrating feeder and sloping feeding pipe.
When the grinding mill is at work, all the grinding rollers are rolling in the ring, and the materials are driven to the edge of the turnplate by the centrifugal force and fall down into the grinding chambers where the materials are repeatedly pressed, crushed and grinded by the rollers.
The high-pressure air blower constantly inhales air within the grinding mill and, in turn, the airflow with crushed materials are brought to the classifier whose high-speed impeller will screen the airflow: the unqualified particle size will fall and return to the mill for being reground while the qualified particle size mixed with air will go into the cyclone powder collector. Most of the qualified powders will fall and exit from the discharging valve at the bottom; a small proportion of the fine powders, with airflow, moves to the dust cleaner, and clings to the surface of the filter bags. At the same time, the fine powders clinging to the surface fall down by the sudden vibration of the filter bags, which is caused by the instantly ejected high-pressure gas controlled by the pulse valve. The materials from the above two lots are sent by the conveyor at the bottom to get finished powders packed. In addition, filtered clean air will be emitted from the air outlet of muffler in the end.
If you'r interested in our micronizer, micronizer equipment, please contact us.
